Novastar VX400 | VX400 Pro | VX600 Pro| VX1000 Pro| VX2000 Pro All-in-One Controller

The Novastar VX2000 Pro, VX1000 Pro, VX600 Pro, VX400 Pro and VX400 All-in-One Controllers provide powerful LED display management, supporting up to 13 million pixels for the VX2000 Pro, 6.5 million pixels for the VX1000, 3.9 million pixels for the VX600, and 2.6 million pixels for the VX400. These controllers feature a variety of input/output connectors, multiple layering options, and advanced preset management for seamless display control in diverse applications.

Categories:LED Controller System

Add To Basket Get A Quote

Product Description

Novastar VX400 | VX400 Pro| VX600 Pro| VX1000 Pro| VX2000 Pro All-in-One Controller Description

The Novastar VX series offers high-performance all-in-one controllers designed for LED display management. The VX2000 Pro, VX1000, VX600, and VX400 models provide exceptional image processing, supporting up to 13 million pixels, making them ideal for large-scale displays. These devices are equipped with a wide range of input and output connectors, allowing for seamless integration and control across various display setups. Whether you are working on a large LED installation or a smaller, more complex setup, the VX series ensures flexibility, scalability, and excellent performance.

Novastar VX400 | VX400 Pro| VX600 Pro| VX1000 Pro| VX2000 Pro All-in-One Controller Specification:

Device Model	VX400 Pro	VX600 Pro	VX1000 Pro	VX2000 Pro
Loading Capacity	2.6 million pixels	3.9 million pixels	6.5 million pixels	13 million pixels
Max Width (pixels)	10240	10240	10240	16384
Max Height (pixels)	8192	8192	8192	8192
Layers	6 *2K×1K	6 *2K×1K	6 *2K×1K	12 *2K×1K
Input Connectors	1× HDMI 2.0（IN&LOOP） 2× HDMI 1.3 1× 3G-SDI（IN&LOOP） 1× 10G OPT Port（OPT1） 1× USB3.0	1× HDMI 2.0（IN&LOOP） 2× HDMI 1.3 1× 3G-SDI（IN&LOOP） 1× 10G OPT Port（OPT1） 1× USB3.0	1× HDMI 2.0（IN&LOOP） 2× HDMI 1.3 1× 3G-SDI（IN&LOOP） 1× 10G OPT Port（OPT1） 1× USB3.0	1× 12G-SDI(IN&LOOP) 1× DP 1.2 2× HDM 2.0 4× HDMI 1.3 2× OPT 1× USB3.0
Output Connectors	4× Ethernet Ports 1× HDMI1.3 1× HDMI 2.0 LOOP 1× 3G-SDI LOOP 2× OPT	6× Ethernet Ports 1× HDMI1.3 1× HDMI 2.0 LOOP 1× 3G-SDI LOOP 2× OPT	10× Ethernet Ports 1× HDMI1.3 1× HDMI 2.0 LOOP 1× 3G-SDI LOOP 2× OPT	20× Ethernet Ports 1× HDMI1.3 4× OPT 1× 12G-SDI LOOP 4× OPT
Presets	256	256	256	256
Control Connectors	2× Ethernet Port 1× USB	2× Ethernet Port 1× USB	2× Ethernet Port 1× USB	2× Ethernet Port 1× USB

Novastar VX400 | VX400 Pro | VX600 Pro| VX1000 Pro| VX2000 Pro All-in-One Controller
